Kitchen 2-in-1 Water & Foam Sensor Faucet Solution
Solution Overview
The kitchen is the most water-intensive and complex space in any home. Traditional kitchen faucets offer only a single water flow function, requiring separate soap dispensers or detergent bottles, resulting in clutter and inefficiency. The C1 Kitchen 2-in-1 Sensor Faucet Solution integrates hands-free water dispensing and foam dispensing into a single faucet body. Simply wave your hand at the sensor zone for water, or switch zones for rich foam — completely eliminating countertop clutter and multi-step operations.
The solution is built on three core modules: high-sensitivity dual sensor module (recognizing hand approach and zone switching), foam generation and delivery assembly (built-in air-liquid mixing pump with dedicated foam channel), and intelligent control board (coordinating water/foam logic and safety protection). Sensor response time ≤0.5s, built-in 500ml foam liquid reservoir providing 2-3 months of maintenance-free operation for typical household use.
Traditional Setup vs C1 Solution
Core Features
Two independent sensor zones built into the faucet body: lower zone (10±2cm) triggers clean water flow, side zone (15±2cm) triggers foam dispensing. Natural gesture-based switching with zero learning curve. Auto standby after 3 minutes of continuous sensor activation.
Direct Stream: high-pressure rinse for large pots and produce.
Aerated Soft Flow: gentle wash for dishes and hands.
Rich Foam: deep grease removal, air-liquid ratio 1:8-1:12 adjustable. Three modes cover every kitchen cleaning scenario.
GIBO proprietary micro air-liquid mixing pump produces dense, creamy foam at a 1:8-1:12 ratio. Anti-clog design with stainless steel mesh filter. 500ml reservoir provides 2-3 months of continuous use. Compatible with most commercial liquid detergents — no proprietary consumables required.
Standby power ≤0.2mW. Battery-only mode delivers approximately 12 months of runtime on 4x AA alkaline cells. AC/DC dual-power version auto-switches to mains power while trickle-charging backup batteries, providing 3-5 days of cordless operation during power outages.
The control board continuously monitors water flow rate and foam line status. Upon detecting abnormal flow (exceeding preset threshold) or line leakage, it automatically closes the solenoid valve and cuts power. Protection response time ≤1 second, shutoff success rate ≥99.5%.
Customizable pull-down spray head extends up to 60cm via flexible hose for cleaning sink corners and large cookware. Features spring-loaded auto-retraction and magnetic docking — patented design (ZL201820847903.7, ZL201920200663.6). Ideal for double-bowl and large single-bowl sinks.
All water-contact components use food-grade materials: SUS304 stainless steel (GB/T 3280 certified), zinc alloy with SGS lead-free certification, food-grade silicone rubber seals, and PP food-grade foam channel. Full compliance with GB 18145-2014 and GB 25501-2010 national standards.
The faucet body supports 160° wide-angle rotation covering both bowls of a double sink. Precision stainless steel bearing mechanism rated for 100,000+ rotation cycles without loosening. Factory-tested with 200-hour salt spray certification for long-term corrosion resistance.
Technical Specifications
Application Scenarios
Built-in foam system eliminates countertop soap bottles for a clean, minimalist look. SUS304 stainless steel or brass chrome finishes complement modern, luxury, and industrial design styles. Recommended: GBL-91605 (dTOF laser), GBL-6178 (water+soap integrated).
Three output modes dramatically boost washing efficiency; 500ml reservoir reduces refill frequency. IP65 protection and 500K cycle life ensure reliability under heavy use. Recommended: GBL-6174 (brass chrome) AC/DC version.
Full sensor operation eliminates twisting or pressing handles — all water tasks completed with a simple wave. Adjustable sensor sensitivity; optional foot switch auxiliary trigger. Recommended: GBL-6175 (ABS lightweight).
Integrated design fully embeds the soap dispenser function into the faucet, matching high-frequency hotel usage. Customizable faucet color, finish, and logo silk-screening. AC/DC power version compatible with hotel smart control systems.
All functional parameters can be preset via the control board, ensuring identical performance across every outlet. Adjustable foam ratio to match different branded detergents. IP65 and self-cleaning anti-clog design minimize maintenance frequency.
Compatible Product Matrix
Patents & Certifications
ODM Customization Options
Redefine Your Kitchen Experience
C1 Kitchen 2-in-1 Water & Foam Sensor Faucet Solution — effortless water use for every kitchen task
Technical data sourced from GIBO Sensor Lab test reports | Sensor range parameters based on lab standard conditions (25°C, 60%RH)
GIBO | Sensor Faucet ODM Expert | www.gibosensor.com
