1. Solution Overview

1.1 The Power Challenge for Smart Sanitary Ware

Sensor faucets, smart toilets, and automatic soap dispensers all face a fundamental reliability question: how to maintain uninterrupted power supply across diverse installation environments. Battery power is convenient but requires periodic replacement, creating a maintenance burden for commercial venues. AC mains power is reliable but limits installation locations and introduces wiring complexity. The ideal solution must intelligently and automatically manage both power sources — battery and AC — with seamless failover switching.

In addition, wet bathroom environments place stringent demands on power supply safety: waterproof sealing, short-circuit protection, overcurrent protection, and surge immunity are all non-negotiable requirements. A poorly designed power adapter can become a single point of failure that renders the entire sensor control system inoperable.

1.2 The GIBO A7 Solution

The GIBO A7 intelligent power adapter module is purpose-built for sensor sanitary ware applications, supporting simultaneous AC mains (110–240V) and DC battery (6V, 4×AA) inputs with built-in intelligent switching logic. When AC mains power is available, the module draws from AC and simultaneously charges the backup battery; when AC power is lost or unstable, the module seamlessly switches to battery power within microseconds, ensuring zero interruption to sensor operation.

The A7 integrates multiple safety protection features including short-circuit protection, overcurrent protection, reverse polarity protection, and a smart anti-overflow power-off safety mechanism (Core Technology #13). The IP65-rated sealed enclosure withstands the wet bathroom environment, providing reliable long-term operation for mission-critical sensor sanitary ware installations.

---

2. Performance Specifications

---

3. Key Features

3.1 AC/DC Intelligent Switching

Built-in intelligent power management IC continuously monitors both AC mains and battery voltage levels. When AC input is detected and stable, the module routes AC power to the load while simultaneously activating a trickle-charge circuit for the backup battery. Upon AC failure or voltage sag below the brownout threshold, the module switches to battery power within ≤100μs — far faster than any downstream sensor controller's power-hold time, ensuring zero operational interruption.

3.2 Multi-Layer Safety Protection

The A7 integrates a comprehensive safety architecture based on GIBO Core Technology #13 (Smart Anti-Overflow Power-Off Safety Protection). Real-time monitoring circuits detect abnormal conditions including output short-circuit, sustained overcurrent (>1.8A), battery reverse polarity insertion, AC input surge, and internal overheating (>85°C). Any anomaly triggers an immediate output shutdown and fault indicator activation, with automatic recovery after the fault condition is cleared.

3.3 Wide-Range AC Input

Universal AC input range of 110–240V with 50/60Hz auto-detection makes the A7 compatible with power grids worldwide. The built-in active PFC (Power Factor Correction) circuit achieves >0.9 power factor, meeting international energy efficiency regulations while minimizing harmonic pollution on the mains line.

3.4 Ultra-Low Standby Consumption

No-load standby power consumption ≤0.3W, compliant with EU ErP Directive energy efficiency requirements. When the connected sensor device enters deep sleep, the A7 automatically enters burst-mode operation, further reducing its own power draw while maintaining output regulation readiness.

3.5 Waterproof IP65 Enclosure

Fully sealed IP65-rated enclosure with cable gland entries protects internal electronics from water spray, dust ingress, and condensation. The potting compound encapsulation on critical components provides an additional moisture barrier, enabling installation in under-sink cabinets and other high-humidity locations without degradation.

3.6 Compact & Installation-Friendly

With compact dimensions of 80×55×35mm, the A7 fits easily into tight under-sink spaces, false ceilings, and service access panels. Pre-wired input/output pigtails with color-coded connectors simplify field installation — no electrician required for basic setup. An LED status indicator on the enclosure provides at-a-glance power status: green for AC power, amber for battery, red for fault.

---

4. Application Scenarios

4.1 Commercial Public Restrooms

In shopping malls, airports, and office buildings, sensor faucets and flush valves operate continuously throughout the day. The A7's dual-power architecture ensures that even during brief power outages or maintenance work, sensor sanitary ware continues functioning on battery backup — eliminating the hygiene and user experience issues of non-functioning facilities.

4.2 Hotel Guestroom Sanitary Ware

Hotel bathrooms require both reliability and aesthetics — exposed batteries or bulky power bricks degrade the premium experience. The A7 can be concealed behind panels or inside service compartments while drawing AC power, with the battery serving as an invisible backup. The compact form factor enables installation in space-constrained hotel vanity units.

4.3 Residential Smart Bathroom Retrofit

For residential users upgrading from manual faucets to sensor faucets, the A7 provides a professional-grade power solution. Users can initially operate on battery power alone for a wire-free installation experience, then add AC power later if the battery replacement interval becomes inconvenient. The dual-power design future-proofs the installation.

4.4 Healthcare & Aged-Care Facilities

Hospitals and nursing homes require 100% uptime for sensor sanitary ware to maintain infection control protocols. The A7's seamless switching and comprehensive safety protections provide the reliability and safety certification (medical-grade isolation) required for healthcare environments. The fault indicator enables staff to proactively identify and resolve power issues before they affect operation.

4.5 Outdoor & Semi-Outdoor Installations

Poolside showers, outdoor kitchen faucets, and garden tap sensor controllers face exposure to rain, UV, and temperature extremes. The A7's IP65 enclosure and wide operating temperature range (-10°C to 60°C) make it suitable for protected outdoor installations where standard power adapters would quickly fail.

---

5. Compatible Products

---

6. Patents & Certifications

---

7. ODM Customization Services

---

Data Source: Technical data from GIBO official website (www.gibo.com.cn), enterprise EEAT knowledge base, and product specifications. Safety certifications independently verified by accredited testing laboratories.

>
