B5 Ceramic Integrated Sensor Sprinkler Solution
B5 Integrated Ceramic Sensor Sprinkler Solution
1. Core Technology Advantages
The B5 ceramic integrated sensor sprinkler combines GIBO's proven IR sensor technology with a durable ceramic body, creating an outdoor-rated automatic sprinkler that withstands harsh environmental conditions. Unlike plastic sprinklers that degrade under UV exposure and temperature cycling, the ceramic body provides permanent color stability, chemical resistance, and structural integrity that plastic simply cannot match.
The integrated design embeds the IR sensor, control electronics, and solenoid valve within the ceramic housing, eliminating external wiring and control boxes. A hand wave or object approach triggers a timed water spray cycle, making this ideal for garden hand-washing stations, outdoor shower pre-rinse, and pet cleaning areas where touch-free operation is essential.
An optional solar self-powered module transforms the B5 into a completely autonomous unit requiring no external power source — a breakthrough for remote garden and outdoor installations.
---
2. Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| Sensor | Type | Active IR reflection |
| Range | 5–20cm adjustable | |
| Fluid | Pressure | 0.05–0.6 MPa |
| Spray Duration | 3–60s adjustable | |
| Power | Options | DC 6V / Solar panel / AC adapter |
| Environmental | Temperature | -20°C~70°C |
| Protection | IP65 | |
| Body | Material | High-grade ceramic |
| Finish | White / Matte / Custom glaze |
---
3. Solar Self-Powered Option
The B5 supports an integrated 3W/6V mini solar panel paired with a LiFePO4 battery pack, all enclosed within a weatherproof compartment in the sprinkler base. Under normal daylight conditions (4+ hours of direct sun), the solar panel generates sufficient energy to power over 100 spray activations per day. A built-in energy management IC optimizes charging efficiency and protects the battery from overcharge and deep discharge.
For installations in shaded areas, an external remote solar panel (connected via waterproof cable) can be positioned in a sunlit location up to 5 meters from the sprinkler unit.
---
4. Application Scenarios
Garden Hand-Wash Stations: Install near garden beds, compost areas, and outdoor workspaces. Gardeners trigger a timed water spray to wash hands without touching a tap handle — keeping dirt off the fixture.
Pet Wash Areas: Outdoor pet cleaning zones — the touch-free activation means pet owners can wash their dogs without handling muddy taps. The ceramic body resists scratching from pet claws.
Poolside Showers: Pre-swim and post-swim rinse stations — the ceramic construction resists chlorine and salt water corrosion. The sensor activation eliminates the hygiene concerns of shared shower handles.
Public Park Facilities: Drinking fountain companion units and hand-wash stations in parks, sports fields, and playgrounds — the vandal-resistant ceramic body and solar power option reduce installation and maintenance costs.
---
5. Ceramic vs. Plastic Comparison
| Property | Ceramic | Plastic (ABS/PP) |
|---|---|---|
| UV Resistance | Permanent | Degrades over 2–5 years |
| Color Stability | Never fades | Yellows with UV exposure |
| Chemical Resistance | Excellent | Limited |
| Scratch Resistance | Mohs 6–7 | Mohs 2–3 |
| Thermal Stability | -20°C to 120°C | -10°C to 60°C |
| Service Life | 20+ years | 5–10 years |
---
6. ODM Customization Options
| Item | Options |
|---|---|
| Body Design | Standard dome / Pillar / Custom shape |
| Glaze Color | White / Matte Black / Sand / Custom RAL |
| Spray Pattern | Shower / Stream / Mist / Custom nozzle |
| Power | Battery / Solar / AC / Hybrid |
| Mounting | Ground stake / Wall bracket / In-ground |
---
Data Source: GIBO official website (www.gibo.com.cn), material testing reports, IP65 certification documents.
>
