D1 Smart Sensor Shower Foam Spray Head Solution
D1 Smart Sensor Shower Foam Shower Head Solution
1. Solution Overview
The D1 Smart Sensor Shower Foam Shower Head reimagines the shower experience by integrating touch-free IR sensor control with an automatic foam infusion system. A hand wave in front of the sensor toggles water flow on/off, eliminating the need to adjust physical handles with soapy hands. An integrated foam generation module draws liquid body wash from a refillable reservoir, mixes it with air and water, and delivers rich, creamy foam through dedicated foam nozzles — transforming a standard shower into a spa-like experience.
The foam shower head delivers three spray modes (rain, massage, and foam) selectable via sensor gestures, with automatic water shutoff when not in use to prevent waste. The foam infusion system reduces body wash consumption by approximately 50% compared to manual application, as the pre-aerated foam provides superior coverage with significantly less product.
---
2. Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| Control | Sensor | IR gesture recognition (wave on/off, mode switch) |
| Spray Modes | Rain / Massage / Foam (3 modes) | |
| Foam | Reservoir | 300ml refillable (integrated in handle) |
| Foam Ratio | 1:4 liquid to foam expansion | |
| Water | Flow Rate | 6–9 L/min (rain), 4–6 L/min (foam) |
| Auto Shutoff | After 3min inactivity | |
| Power | Battery | Built-in Li-ion, 6+ months (micro-USB recharge) |
| Mechanical | Connection | Standard G1/2" shower hose |
| Protection | Rating | IPX7 (immersion-proof electronics) |
---
3. Key Features
3.1 Gesture-Controlled Water Flow
A single hand wave toggles water on/off — ideal for soap-lathering and shampooing phases when continuous water flow is unnecessary. A double-wave gesture switches between spray modes (rain → massage → foam → rain). The IR sensor is positioned on the shower head face, angled downward to detect hand gestures naturally made below the head.
3.2 Integrated Foam Infusion
A micro-peristaltic pump in the handle draws body wash concentrate from the 300ml reservoir and injects it into a mixing chamber where water and air combine to create dense, creamy foam. The foam is dispensed through a dedicated ring of micro-nozzles surrounding the main spray face, providing even body coverage with significantly less product than manual lathering.
3.3 Water-Saving Auto Shutoff
If no gesture activity is detected for 3 minutes, the shower head automatically shuts off water flow. This feature prevents the common scenario of water running unnoticed while the user is lathering or attending to other tasks, saving hundreds of liters per month in typical household use.
---
4. Application Scenarios
Residential Bathrooms: Transform daily showers into a spa experience with gesture-controlled foam infusion. The water-saving auto shutoff reduces household water bills.
Premium Hotels & Resorts: Differentiate guest bathrooms with a memorable shower experience. The refillable foam reservoir allows hotels to use their branded body wash.
Gyms & Fitness Centers: Touch-free water control eliminates hygiene concerns with shared shower handles. Foam mode reduces body wash consumption and refill frequency.
Senior & Assisted Living: Gesture control eliminates the fine motor coordination required to operate traditional shower handles. The auto shutoff provides safety for users who may forget to turn off the water.
---
5. ODM Customization
| Item | Options |
|---|---|
| Spray Modes | 3 modes / Custom mode configurations |
| Foam Reservoir | 300ml / 500ml / External bulk feed |
| Face Design | Round / Square / Oval / Custom |
| Charging | Micro-USB / USB-C / Wireless charging |
---
Last Updated: 2026-06-14 | GIBO | www.gibo.com.cn
